Custom Plastic Extrusion

The definitive process for creating custom, continuous profiles. We transform thermoplastic pellets into high-quality tubes, rods, channels, and custom shapes for a wide range of applications.

A blue anodized aluminum extrusion, illustrating the concept of a constant profile shape

The Process: Pushing Plastic Through a Die

Plastic extrusion is a high-volume manufacturing process where raw plastic material (in the form of pellets) is melted and forced through a custom-made tool called a die. The die has a specific cross-sectional shape, and the molten plastic takes this shape as it is pushed through.

As the plastic exits the die, it is cooled (typically in a water bath) and solidifies, forming a long, continuous profile with the desired shape. This profile is then pulled by rollers and cut to its final length. It is an extremely efficient process for creating parts that have a constant cross-section along their length.

A sample of different colored engineering plastics, the raw material for extrusion

Common Applications for Plastic Extrusion

Pipes & Tubing

From plumbing pipes (PVC) and industrial tubing (HDPE) to medical catheters (PEEK), this is one of the largest applications of extrusion.

Window & Door Profiles

The frames and seals for vinyl (PVC) windows and doors are created as long, complex extruded profiles that are then cut and assembled.

Wire Insulation

The process of coating electrical wire with a protective, insulating layer is a form of extrusion where the wire is pulled through the center of the die.

Custom Profiles & Trim

Creating custom decorative trim, channels, weather stripping, and edge guards for a huge variety of consumer and industrial products.

Plastic Extrusion FAQ

What materials can be extruded?

A wide range of thermoplastics can be extruded. The most common include PVC, HDPE, LDPE, Polypropylene, ABS, and Polycarbonate. The choice depends on the required flexibility, durability, and cost.

What is co-extrusion?

Co-extrusion is a process where two or more different materials are extruded through a single die to create a profile with multiple layers. For example, a rigid PVC profile could be co-extruded with a soft, flexible TPE seal along one edge, creating a single, integrated part.

How does extrusion compare to other processes like molding or machining?

Extrusion is only suitable for parts that have a constant cross-section. If your part has changes in its profile along its length (like holes, bosses, or pockets), it must be made with another process like injection molding or CNC machining, or have those features added in a secondary machining operation after extrusion.
